Move mouse coursor or your finger upon an image
and you can see the image without labells
|
KIDNEY
Stained with haematoxylin and eosin
1 - renal corpuscle
2 - proximal convoluted tubules
3 - distal convoluted tubules
4 - collecting tubule
|
|
KIDNEY
cortex
Stained with haematoxylin and eosin
1 - renal corpuscle
2 - proximal convoluted tubules
3 - distal convoluted tubules
4 - collecting tubule
|
|
KIDNEY
cortex
Stained with haematoxylin and eosin
1 - renal corpuscle
2 - proximal convoluted tubules
3 - distal convoluted tubules
4 - Bowman's capsulae space
|
|
KIDNEY
cortex
Stained with haematoxylin and eosin
1 - renal corpuscle
2 - proximal convoluted tubules
3 - distal convoluted tubules
|
|
KIDNEY
cortex
Stained with haematoxylin and eosin
1 - renal corpuscle
2 - proximal convoluted tubules
3 - distal convoluted tubules
4 - collecting tubule
|
|
KIDNEY
medulla
Stained with haematoxylin and eosin
1 - thick ascending limb of the loop of Henle
2 - thin descending limb of the loop of Henle
3 - collecting tubule
|
|
KIDNEY
medulla
Stained with haematoxylin and eosin
1 - thick ascending limb of the loop of Henle
2 - thin descending limb of the loop of Henle
3 - collecting tubule
|
|
KIDNEY
medulla
Stained with haematoxylin and eosin
1 - thick ascending limb of the loop of Henle
2 - interstitial connective tissue
|
|
KIDNEY
medulla
Stained with haematoxylin and eosin
1 - thick ascending limb of the loop of Henle
2 - interstitial connective tissue
|
|
KIDNEY
absorbtion of dye by proximal convoluted tubules
Stained with haematoxylin and eosin
1 - renal corpuscle
2 - proximal convoluted tubule
3 - distal convoluted tubule
4 - collecting tubule
5 - capsule of the kidney
|
|
GLOMERULAR FILTER
(border between blood and primary urina)
Electron microscopy image
1 - capillary endothelium of the glomerulus
2 - podocyte pedicles, or secondary foot processes
(inner layer of the glomerular (Bowman's) capsulae)
3 - glomerular basement membrane; there are 3 layers:
middle layer is more dark (lamina densa), outher layers look
lighter (laminae rara)
|
|
GLOMERULAR FILTER
Electron microscopy image
|
|
