SPINAL CORD
Impregnated with silver nitrate
1 - gray matter
2 - white matter
3 - ventral horns of gray matter
4 - dorsal horns of gray matter
5 - lateral horns of gray matter
|
![](../images/nerv/spinal-cord-01-l.jpg) |
SPINAL CORD
Impregnated with silver nitrate
1 - gray matter (ventral horns)
2 - white matter
3 - nervous cell bodies
4 - nervous fibers in transverse cut
(convey tracts)
|
![](../images/nerv/spinal-cord-02-l.jpg) |
SPINAL CORD
Impregnated with silver nitrate
1 - gray matter (ventral horns)
2 - white matter
3 - nervous cell bodies
4 - nervous fibers in transverse cut
(convey tracts)
|
![](../images/nerv/spinal-cord-03-l.jpg) |
SPINAL GANGLION
Stained with haematoxylin and eosin
1 - cell bodies of neurons (located by groups)
2 - nerve fibers
|
![](../images/nerv/spinal-ganglion-01-l.jpg) |
SPINAL GANGLION
Stained with haematoxylin and eosin
1 - cell bodies of neurons (pseudo-unipolar neurons)
2 - nerve fibers
|
![](../images/nerv/spinal-ganglion-02-l.jpg) |
SPINAL GANGLION
Stained with haematoxylin and eosin
1 - cell bodies of neurons (pseudo-unipolar neurons)
2 - satellite cells
3 - nerve fibers
4 - interlayers of connective tissue
|
![](../images/nerv/spinal-ganglion-03-l.jpg) |
SPINAL GANGLION
Stained with haematoxylin and eosin
1 - cell bodies of neurons (pseudo-unipolar neurons)
2 - satellite cells
3 - nerve fibers
4 - interlayers of connective tissue
|
![](../images/nerv/spinal-ganglion-04-l.jpg) |
SYMPATHETIC GANGLION
Impregnated with silver nitrate
1 - cell bodies of neurons (multipolar neurons)
2 - nerve fibers
|
![](../images/nerv/veget-ganglion-01-l.jpg) |
SYMPATHETIC GANGLION
Impregnated with silver nitrate
1 - cell bodies of neurons (multipolar neurons)
2 - nerve fibers
|
![](../images/nerv/veget-ganglion-02-l.jpg) |
