MICROSCOPIC HISTOLOGY IMAGES - NERVOUS SYSTEM

HISTOLOGY IMAGES

NERVOUS SYSTEM
cerebellar cortex

Move mouse coursor or your finger upon an image
and you can see the image without labells

CEREBELLAR CORTEX
Impregnated with silver nitrate
1 - molecular layer
2 - ganglionic layer (Purkinje cell layer)
3 - granular cell layer
4 - Purkinje neurons (cells)
5 - fold of the cortex
6 - white matter

CEREBELLAR CORTEX
Impregnated with silver nitrate
1 - molecular layer
2 - ganglionic layer (Purkinje cell layer)
3 - granular cell layer
4 - Purkinje neurons (cells)
5 - fold of the cortex
6 - white matter
7 - dendrites of Purkinje cells
8 - stellate neurons (cells) and basket neurons (cells)
11 - granular neurons (cells)

CEREBELLAR CORTEX
Impregnated with silver nitrate
1 - molecular layer
2 - ganglionic layer (Purkinje cell layer)
3 - granular cell layer
4 - Purkinje neurons (cells)
5 - fold of the cortex
6 - white matter
7 - dendrites of Purkinje cells
8 - stellate neurons (cells) and basket neurons (cells)
9 - stellate neurons
10 - axons of stellate and basket neurons,
twining cell bodies of Purkinje neurons
11 - granular neurons (cells)

CEREBELLAR CORTEX
Impregnated with silver nitrate
1 - molecular layer
2 - ganglionic layer (Purkinje cell layer)
3 - granular cell layer
4 - Purkinje neurons (cells)
7 - dendrites of Purkinje cells
8 - stellate neurons (cells) and basket neurons (cells)
9 - stellate neurons
10 - axons of stellate and basket neurons,
twining cell bodies of Purkinje neurons
11 - granular neurons (cells)

CEREBELLAR CORTEX
Stained with haematoxylin and eosin
1 - molecular layer
2 - ganglionic layer (Purkinje cell layer)
3 - granular cell layer
4 - Purkinje neurons (cells)

CEREBELLAR CORTEX
Stained with haematoxylin and eosin
1 - molecular layer
2 - ganglionic layer (Purkinje cell layer)
3 - granular cell layer
4 - Purkinje neurons (cells)

CEREBELLAR CORTEX
Stained with haematoxylin and eosin
1 - molecular layer
2 - ganglionic layer (Purkinje cell layer)
3 - granular cell layer
4 - Purkinje neurons (cells)
